Single Motor Standing Desk Frame,Height-adjustable Desk Frame with Memory Controls, CE Certified, Height Adjustable, Table Legs, Ergonomic Standing Desk Base


Customized Ergonomic Height: 75-115cm - With a smooth electric lifting system and a user-friendly LED control panel with 4 memory functions, our height-adjustable desk offers individual options for optimal comfort. You can seamlessly switch between sitting and standing with a single pressure.
Improved stability and safety -Our computer desk has been designed to hold a weight of up to 80 kg and uses a thick aluminium lifting frame connected to thick composite worktop. The table also passes the amazing 50,000 lifting tests, ensuring years of reliable use.
Stylish and organised work surface - With optional desktopp, our spacious worktop offers enough space for your computer and other important things. With thoughtful design, including 2 cable grommets and 2 hooks, it keeps your work surface tidy and without clutter. The perfect companion for enhancing home, office or any other work surface.
High-quality and quiet motor – the lifting movement glides like silk and works with an extremely low noise level of ≤50 db. This ensures a quiet and distraction-free working environment, so you can fully focus on your tasks, whether you work, play or learn.
Optimised assembly - Experience a hassle-free setup process with our comprehensive yet concise installation guide and cleverly numbered accessories. You can do the assembly quickly and easily on your own. In addition, we are committed to environmental protection and use high-quality, recyclable packaging to guarantee sustainability.
Availability:
  • ZDTD-2VX-W8

  • ZHIDING

1NameSingle motor standing desk

2

Code

 ZDTD-2VXJ2.2-W8-950-U           ZDTD-2VXJ2-W8-950-U

3

Number of Motor

Single motor

4

Lifting Column / Legs

2 stage Rectangle reserved lifting column
Outside tube:65*45*1.2mm inner tube:60*40*1.2mm

5

Height adjustable range/ stroke

700-1150mm/ 450mm

6

Duty Cycle

10%,Max 2 min on,18 min off.

7

Telescopic frame range

950mm Fixed (fit 100-120cm tabletop)

8

lifting speed

17-20mm/s

9

Noise Level

≦50dB

14

Max Load capacity

70kgs

22

Foot size & Thickness

steel-tube foot,580*60*20

24

Side bracket length & thickness

470*30*2.5mm

26

power

29V 2A

10

memory set

2/3/4 memory set

10

Memory Setting

2/3/4 button keys press controller

11

Overload protection

yes

12

(Overhot) Thermal protection

yes

13

Anti-collision

yes

15

Optional desk base color

Black RAL9005 /White RAL 9016 /Grey RAL7045

17

Weight(NW/GW)

13KGS/15KGS

18

Main feature

small,affordable

19

Package & Size

Only deskframe:990*301*13cm




photobank - 2025-04-27T094630.502photobank - 2025-04-27T102249.278photobank - 2025-04-27T094521.453photobank - 2025-04-27T094536.890photobank - 2025-04-27T101917.638photobank - 2025-04-27T094604.509
